The DSX Electric is the mountain biker’s E Gravel bike. Similar to the Lombard E but with that familiar hand positioning of flat bars for comfort and confidence. The Marin DSX Electric features a Bosch SX Sprint power unit and a fully integrated 400w powertube battery. The frame now utilizes our all-new Series 4 Beyond Road Aluminum frameset and full carbon fork with tapered steerer.
Durable components including high volume tires, hydraulic disc brakes, 1x12 Shimano gearing and a dropper post for maximizing downhill prowess and confidence.
Perfect for racking up road miles, daily grinds to work, multi-day epics and flowy singletrack, the DSX Electric is our all new killer-commuter.
Specs
| FRAME | All-New Series 4 Beyond Road E, 6061 Aluminum, One-Piece, Hydroformed Downtube & Motor Mount, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
| FORK | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount, Disc, Fender Eyelets |
| RIMS | Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible |
| HUB REAR | Forged Aluminum Alloy, 142x12mm, Disc, 32H |
| HUB FRONT | Forged Aluminum Alloy, 100x12mm, Disc, 32H |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Vee Tire Co., G-Sport, 700x44, Tubeless Compatible |
| DERAILLEUR REAR | NEW Shimano GRX |
| SHIFT LEVER | NEW Shimano GRX |
| CRANKSET | e*thirteen e*Spec Plus, Forged Arm, 42T Steel Chainring |
| MOTOR | Bosch SX Sprint, 250W, 55Nm, Class 3 (28mph, 45Km/h) |
| CHAIN | KMC E12S |
| CASSETTE | Shimano SLX CSM7100, 10-51T |
| BRAKE, FRONT | Shimano GRX RX820, Flat-Mount Hydraulic Disc, 160mm Rotor |
| BRAKE, REAR | Shimano GRX RX820, Flat-Mount Hydraulic Disc, 160mm Rotor |
| BRAKE LEVERS | NEW Shimano GRX |
| HANDLEBAR | Marin Butted Alloy, Compact 16º Flared Drop |
| STEM | Marin 3D Forged Alloy |
| GRIPS | Marin Adventure Tape |
| HEADSET | FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| SEATPOST | TranzX YSP38J, Size S-M 70mm, Size L-XL 110mm Travel, 27.2mm |
| SADDLE | Marin Beyond Road Concept Elite |
| PEDALS | Nylon Platform |
| KICKSTAND | Removable kickstand mount |
| BATTERY | Bosch CompactTube 400, 400Wh |
| EXTRAS | Bosch MiniRemote HMI, Bluetoth |
| RANGE, CHARGING TIME | 14-85 miles/22-137km (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 3.5 hours (estimated, under ideal conditions) |
