2022 Sinch Jaunt EZ 1 DT
2022 Sinch Jaunt EZ 1 DT
2022 Sinch Jaunt EZ 1 DT

2022 Sinch Jaunt EZ 1 DT

Regular price
$4,299.99 Call us 0800 541 569
Sale price
$4,299.99
includes 15% GST

Enquiry Form

The Jaunt EZ 1 has a comfortable easy step-through frame with an upright riding position for a safe and comfortable ride equipped with carrying and lighting solutions.  Easy mounting and dismounting off this bike make it great for getting around town and enjoying cycle ways. Quality and reliable components throughout will give you confidence to get out and explore. If you want to be active and go the extra distance in comfort and style the Jaunt EZ 1 is perfect for you. A super reliable intuitive pedal assist Shimano drive unit will help you sustain speeds up to 32km/hr and allows you to travel up to 150km on one full charge depending on rider assist mode, terrain and weather conditions. Never stop exploring!!

What’s there to Love

  • Shimano E5000 mid-drive motor is capable of sustaining speeds up to 32 km/hr
  • Shimano STEPs E8014 418Wh Battery extends your riding range up to 150km depending on rider assist mode, terrain and weather conditions
  • SR Suntour NVX30 Suspension fork with 80mm of travel and hydraulic lockout
  • Shimano Alivio 9 Speed components with Shimano Hydraulic disc brakes
  • CST Jack Rabbit 27.5 x 2.4” tyres with puncture protection for trouble free riding
  • Spanninga Front and rear lights with integrated mud guards and rack solutions

Frameset

Frame 6061 E Bike Specific Step-through Aluminum Frame
Front suspension SR Suntour NVX30, 80mm travel with preload adjustment and hydraulic lockout

Motor

Drive Unit Shimano STEPS DU-E5000 250watt 40Nm, 32km/hr
Battery Shimano Steps BT-E8014, 36V 11.6Ah 418Wh
Display Shimano Steps SC-E6100 Cycle Computer.

Wheels

Hubs Shimano TX-505 32H
Rims Alex DP30 Double Wall 27.5" 32H
Tyres CST Jack Rabbit 27.5x2.4" with puncture protection

Drivetrain

Shifter Shimano Alivio SL-M3100 9 Speed
Derailleur Shimano Alivio RD-M3100 9 Speed
Crankset Shimano FC-E5010 with 38T Chainring and double Chainguard
Cassette Shimano Cassette HG200 11-36T 9 Speed
Chain KMC E9 Sport
Pedals Sinch Nylon platform

Components

Brakeset Shimano MT200 Hydraulic disc, 180mm front/160mm rear rotors
Saddle Sinch Comfort 199mm Gel Dual density
Seat Post Sinch Alloy Micro Adjust, 31.6mm
Bar Sinch Alloy Comfort, 26mm rise, 30° sweep, 680mm
Stem Sinch Alloy 31.8mm, Adjustable
Grips Sinch Comfort Gel Lock-on dual density

Accessories

Lights  Spanninga Axendo 25 Front, Solo Rear
Accessories Mudguards, Rear Carrier, Kickstand

Sizes

Weight

XS, S/M, M/L = 27.5"

22.0kg (S/M Size)



Geometry

XS

S/M

M/L

A - Seat Tube 390 435 480
B - Top Tube Horizontal 575 595 615
C - Chain Stay 480 480 480
D - Headtube Length 175 175 185
E - Head Angle 68.5 68.5 68.5
F - Seat Angle 73 73 73
G - Wheelbase 1097.6 1145.1 1165.9
Stack 654.2 654.2 663.5
Reach 375 395 412.2
Crank Length 165 165 170
Stem Length 90 90 90



Size Guide
XS S/M M/L
Rider Height 148-156 154-170 166-180
